Extruded 1 1/4" x 1 1/4" Mini Mesh Chain Link
Extrusion is a process used to manufacture complex cross-sectionals and is ideal for shaping brittle materials.
Our 1 1/4" x 1 1/4" extruded mini mesh undergoes a special process that forms the wire into a durable product with a very smooth surface finish, ensuring clothing won't get snagged on wire.
The small link size makes mini mesh a staple in the high security fence industry. All mini mesh is covered by a warranty, and the high quality material is resistant to corrosive elements and pollutants.
Feet (in Rolls): 25, 50
Gauges/Cores: 3 (.192), 6 (.145), 8 (.117), 9 (.117), 9 (.101), 9 (.095), 11 (.080)
Heights: 18", 24", 36", 42", 48", 60", 72", 84", 96", 108", 120", 132", 144", 156", 168", 180", 192", 204", 216", 228", 240"
Colors: Mini mesh is available in a variety of colors. If you need a color tailored to your needs, we will find it for you! Please contact us for availability.
Find Your 1 1/4" x 1 1/4" Extruded Mini Mesh:
| Fabric Height | Roll Size | Mesh Size | Selvage | Gauge | Weight / Per Foot (LBS) |
| 18 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 0.69 |
| 24 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 0.92 |
| 36 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 1.38 |
| 42 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 1.61 |
| 48 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 1.84 |
| 60 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 2.3 |
| 72 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 2.76 |
| 84 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 3.22 |
| 96 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 3.68 |
| 108 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 4.14 |
| 120 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 4.6 |
| 132 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 5.06 |
| 144 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 5.52 |
| 156 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 5.98 |
| 168 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 6.44 |
| 180 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 6.9 |
| 192 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 7.36 |
| 204 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 7.82 |
| 216 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 8.28 |
| 228 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 8.74 |
| 240 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 11 GA (.080 Core) | 9.2 |
| Fabric Height | Roll Size | Mesh Size | Selvage | Gauge | Weight / Per Foot (LBS) |
| 18 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 1.071 |
| 24 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 1.428 |
| 36 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 2.142 |
| 42 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 2.499 |
| 48 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 2.856 |
| 60 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 3.57 |
| 72 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 4.284 |
| 84 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 4.998 |
| 96 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 5.712 |
| 108 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 6.426 |
| 120 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 7.14 |
| 132 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 7.854 |
| 144 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 8.568 |
| 156 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 9.282 |
| 168 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 9.996 |
| 180 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 10.71 |
| 192 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 11.424 |
| 204 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 12.138 |
| 216 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 12.852 |
| 228 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 13.566 |
| 240 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.095 Core) | 14.28 |
| Fabric Height | Roll Size | Mesh Size | Selvage | Gauge | Weight / Per Foot (LBS) |
| 18 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 1.146 |
| 24 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 1.528 |
| 36 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 2.292 |
| 42 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 2.674 |
| 48 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 3.056 |
| 60 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 3.82 |
| 72 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 4.584 |
| 84 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 5.348 |
| 96 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 6.112 |
| 108 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 6.876 |
| 120 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 7.64 |
| 132 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 8.404 |
| 144 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 9.168 |
| 156 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 9.932 |
| 168 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 10.696 |
| 180 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 11.46 |
| 192 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 12.224 |
| 204 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 12.988 |
| 216 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 13.752 |
| 228 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 14.516 |
| 240 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.101 Core) | 15.28 |
| Fabric Height | Roll Size | Mesh Size | Selvage | Gauge | Weight / Per Foot (LBS) |
| 18 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 1.2 |
| 24 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 1.6 |
| 36 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 2.4 |
| 42 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 2.8 |
| 48 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 3.2 |
| 60 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 4 |
| 72 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 4.8 |
| 84 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 5.6 |
| 96 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 6.4 |
| 108 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 7.2 |
| 120 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 8 |
| 132 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 8.8 |
| 144 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 9.6 |
| 156 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 10.4 |
| 168 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 11.2 |
| 180 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 12 |
| 192 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 12.8 |
| 204 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 13.6 |
| 216 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 14.4 |
| 228 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 15.2 |
| 240 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 9 GA (.117 Core) | 16 |
| Fabric Height | Roll Size | Mesh Size | Selvage | Gauge | Weight / Per Foot (LBS) |
| 18 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 1.365 |
| 24 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 1.82 |
| 36 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 2.73 |
| 42 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 3.185 |
| 48 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 3.64 |
| 60 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 4.55 |
| 72 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 5.46 |
| 84 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 6.37 |
| 96 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 7.28 |
| 108 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 8.19 |
| 120 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 9.1 |
| 132 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 10.01 |
| 144 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 10.92 |
| 156 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 11.83 |
| 168 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 12.74 |
| 180 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 13.65 |
| 192 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 14.56 |
| 204 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 15.47 |
| 216 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 16.38 |
| 228 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 17.29 |
| 240 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 8 GA (.117 Core) | 18.2 |
| Fabric Height | Roll Size | Mesh Size | Selvage | Gauge | Weight / Per Foot (LBS) |
| 18 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 1.95 |
| 24 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 2.6 |
| 36 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 3.9 |
| 42 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 4.55 |
| 48 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 5.2 |
| 60 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 6.5 |
| 72 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 7.8 |
| 84 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 9.1 |
| 96 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 10.4 |
| 108 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 11.7 |
| 120 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 13 |
| 132 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 14.3 |
| 144 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 15.6 |
| 156 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 16.9 |
| 168 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 18.2 |
| 180 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 19.5 |
| 192 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 20.8 |
| 204 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 22.1 |
| 216 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 23.4 |
| 228 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 24.7 |
| 240 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 6 GA (.145 Core) | 26 |
| Fabric Height | Roll Size | Mesh Size | Selvage | Gauge | Weight / Per Foot (LBS) |
| 18 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 24 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 36 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 42 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 48 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 60 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 72 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 84 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 96 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 108 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 120 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 132 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 144 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 156 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 168 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 180 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 192 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 204 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 216 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 228 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) | |
| 240 | 25' or 50' | 1 1/4" x 1 1/4" | Knuckle Knuckle | 3 GA (.192 Core) |
